Specification

StyleSpin-On Filter
Efficiency 130µ @ β2
Efficiency 230µ @ β1000
Outer Diameter 95.0 mm
Length 154.0 mm
Thread1 3/8"-12 UNF 2B
MediaCellulose
Δ Collapse Pressure 34.5 BAR
Seal MaterialNitrile
Temperature Range -30 - +100°C

FilterFinder Approved Product

We Guarantee The FilterFinder FF212165B Is

What This Means For You

  • Simple No Quibble 45 Day Returns.
  • 1 Year Manufacturer Warranty.
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
30µ @ β2
Efficiency 2 30µ @ β1000
Style Spin-On Filter
Outer Diameter 95.0 mm
Inner Diameter
Length 154.0 mm
Media Type Cellulose
Flow Direction
Thread 1 3/8"-12 UNF 2B
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 34.5 BAR
Seal Nitrile
Temperature Range -30 - +100°C
